GIERTH HF200Apower

Simple operation with the anatomical program

The GIERTH HF200Apower with the anatomical program is specially designed and developed for the small animal veterinarian and covers the complete range of veterinary radiography in the field of small animals, birds and exotic pets.

1,200 stored exposure settings help to make the daily routine in a small animal practice as quick and easy as possible. The intuitive user guidance through the anatomical program makes the GIERTH HF200Apower an ideal X-ray unit for the small animal vet.

The updated version leads to an increased (up to 30 %) dose rate.

Short description

• High–frequency X-ray generator with full bridge inverter system
• Weight of 16.6 kg
• Easiest handling due to stored exposure settings for dogs, cats, birds and other pets
• Thickness gauge for measuring object thickness
• Serial interface for connection with digital radiography systems
• Collimator with scale to adjust the size of the light–radiation field
• Collimator light can be activated via the hand switch
• Acoustic and optical timer signal
• Dual laser pointer
• Digital display „X-RAY“, „READY“ and „ERROR“
• Tape measure for the film – focal spot distance
• Aluminium casing

Technical data

Inverter frequency:	62.5 kHz
Power Requirement:	2.5 kVA
Output in 2-kV Steps:	30 – 60 kV = 40 mA (max.) 62 – 70 kV = 35 mA (max.) 72 – 80 kV = 30 mA (max.) 82 – 100 kV = 25 mA (max.)
X-ray tube:	KL31
Focal spot:	1.2 mm x 1.2 mm
Dimensions L x W x H:	405 mm x 290 mm x 230 mm
Total filtration:	2.7 mmAl

GIERTH TR90/30 peak

Most advanced, lightweight portable X-ray unit

The GIERTH TR90/30peak is the perfect solution for the mobile practice. With the TR90/30peak high-quality X-ray images are no longer a problem. The user-friendly operation, the integrated DR interface and the extremely low weight make it the favourite unit for equine practitioners. The GIERTH TR90/30peak comes in a practical transport case.

Short description

• High–frequency X-ray generator with full bridge inverter system
• It only weighs 6.5 kg
• Serial interface for connection with digital radiography systems
• Collimator with scale to adjust the size of the light–radiation field
• Collimator light can be activated via the hand switch
• Acoustic and optical timer signal
• 5 memory buttons
• Dual laser pointer
• Digital display „X-RAY“, „READY“ and „ERROR“
• Tape measure for the film – focal spot distance
• Aluminium casing
• Robust and innovative impact-resistant construction

Technical data

Inverter frequency:	50 kHz
Power Requirement:	1.8 kVA
Output in 2-kV Steps:	40 – 60 kV = 30 mA (max.) 62 – 70 kV = 25 mA (max.) 72 – 80 kV = 20 mA (max.) 82 – 90 kV = 15 mA (max.)
X-ray tube:	KL30
Focal spot:	0.8 mm x 0.8 mm
Dimensions L x W x H:	295 mm x 188 mm x 170 mm
Total filtration:	2.7 mmAl

Trolley stand with spring arm

Trolley stand for all GIERTH X-ray units up to 18.5 kg

The trolley stand for all GIERTH x-ray units up to 18.5 kg and is the perfect choice for the equine clinic or a small animal practice. It can be adjusted continuously via a crank mechanism. The stand can be dismantled for transportation within a very short time.

Short description

• continuous height adjustment by spring arm
• distance between spring arm and stand approx. 30 cm
• robust and versatile
• stand rod can be separated

Technical data

Dimensions (L x W x H):	70 cm x 80 cm x 100 cm (extendible to 220 cm)
Material:	Corrosion-resistant anodised aluminium, Stainless steel rod
Weight:	23 kg
